Specifications
Construction |
All Solid Woods |
Family |
Traditional |
Style |
Small Body |
Bridge Material |
Ebony |
Fingerboard Material |
Rosewood |
Neck Material |
Mahogany |
Nut Material |
Bone |
Saddle Material |
Bone |
Back and Sides Wood |
Solid African Mahogany |
Back Binding |
Rosewood |
Back Center Strip |
Rosewood |
Back Purfling Inlay |
Maple and Black |
Body Top |
Solid Western Red Cedar |
Build |
Small Body |
Color |
Natural (NAT) |
Finish |
Gloss Polyurethane |
Frets to Body |
12 |
Neck Joint |
Spanish Heel |
Neck Shape |
C Shape |
Top Bracing Pattern |
Fan |
Waist Width |
232mm (9 1/8") |
Tuning Machine Buttons |
Black |
Tuning Machine Ratio |
14:1 |
Body Depth Lower Bout |
95mm (3 3/4") |
Body Depth Upper Bout |
90mm (3 1/2") |
Body Length |
479mm (18 7/8") |
Fret Dimensions |
2.0mm (W) x 1.1mm (H) |
Lower Bout Width |
359mm (14 1/8") |
Neck Thickness 1st Fret |
21mm |
Neck Thickness 9th Fret |
24mm |
Nut Width |
50mm (2") |
Overall Length |
965mm (38") |
Scale Length |
630mm (24.8") |
Shipper Carton Dimensions |
108 x 44 x 21 (cm) |
Soundhole Diameter |
84mm (3.3") |
Target Instrument Weight |
3 lbs / 1.4 kg |
Upper Bout Width |
270mm (10 5/8") |
Back Purfling Inlay Pattern & Dimensions |
0.5mm Maple, 0.5mm Black, 0.5mm Maple |
Country of Origin |
China |
Does it contain shell? |
Yes - MOP |
Exclusive |
No |
Frets Total |
19 |
Headplate |
Rosewood |
Headstock Logo |
Cordoba Arches Logo - Mother-of-Pearl |
Included Case |
Cordoba Polyfoam Case |
Number of Strings |
6 |
Nut String Spacing |
43mm |
pcid |
1 |
psid |
2 |
Rosette |
Pearloid Esteso Weave Pattern |
Side Purfling Inlay |
Maple and Black |
Side Purfling Inlay Pattern & Dimensions |
0.5mm Maple, 0.5mm Black, 0.5mm Maple |
Strings |
Savarez Cristal Corum High Tension 500CJ |
Tail Strip |
Rosewood |
Top Binding |
Rosewood |
Top Purfling Inlay |
Padauk, Maple and Black |
Top Purfling Pattern & Dimensions |
0.5 Black, 0.5 Maple, 0.5 Black, 0.5 Padauk, 0.5 Padauk, 0.5 Black, 0.5 Maple, 0.5 Black |
Truss Rod |
Dual Action |
Truss Rod Wrench |
4mm Allen Key |
Tuning |
E-A-D-G-B-E |
Tuning Machines |
Cordoba Premium Gold with Black Buttons |
Tuning Machines Vendor & Model |
Der Jung DJ305GK-P6B (S3) |
Sage Item |
GUCLCOR05274 |
Due to ongoing product development efforts, exact specifications are subject to change from time to time.
