Cordoba

Fusion 12 Cinnamon Burst

Key Features
  • Construction: Solid Top
  • Family: Cutaway & Electric
  • Style: Fusion

Fusion 12 Exotic Top guitars deliver traditional nylon-string tone while also featuring distinctive modern aesthetics. An ultra-thin layer of genuine exotic wood veneer is applied to their solid-spruce tops, resulting in a striking appearance without adversely affecting the tone. The Fusion 12 Cinnamon Burst guitar features richly flamed okoume back and sides, complemented by a matching flamed okoume veneer overlay. Mahogany binding and a hand-inlaid wooden rosette further enhance its unique aesthetics. The guitar produces a warm tone with a snappy response, and its integrated Fishman® Presys Blend pickup system maintains that tone when the instrument is amplified.



  • Solid-spruce top with ultra-thin flamed okoume veneer overlay
  • Flamed okoume back and sides with mahogany binding
  • Fusion neck profile (48mm nut width) with 16" radius ebony fingerboard
  • Integrated Fishman Presys Blend preamplifier and pickup system
  • Traditional bridge placement (12th fret at body) for optimal resonance
  • Soft cutaway body for easy access to upper frets
  • Hand-inlaid wooden rosette



Fishman is a trademark of Fishman Transducers Inc.

Find a Dealer
Specifications
Construction Solid Top
Family Cutaway & Electric
Style Fusion
Bridge Material Pau Ferro
Fingerboard Material Ebony
Neck Material Mahogany
Nut Material Bone
Saddle Material Bone
Back and Sides Wood Flamed Okoume
Back Binding Mahogany
Back Center Strip Mahogany
Back Purfling Inlay 4-ply Maple and Black
Body Top Solid Spruce w/ Flamed Okoume Veneer
Build Fusion
Color Cinnamon Burst
Finish Gloss Polyurethane
Frets to Body 12
Neck Joint Mahogany
Neck Shape Fusion C Shape
Top Bracing Pattern Fan
Waist Width 235mm (9 1/4")
Battery Pack Inside Preamp Compartment - 9V
Battery Pack Installation Location Flip Up Preamp
Electronics Fishman Presys Blend
Replacement Tuning Machine - Bass Tuner Honeycomb NKL/EB BTN Bass (part#98-041-0910)
Replacement Tuning Machine - Treble Tuner Honeycomb NKL/EB BTN Treb (part#98-041-0900)
Tuning Machine Buttons Black
Tuning Machine Ratio 14:1
Body Depth Lower Bout 95mm (3 3/4")
Body Depth Upper Bout 85mm (3 1/3")
Body Length 483mm (19")
Fret Dimensions 2.0mm (W) x 1.1mm (H)
Lower Bout Width 368mm (14 1/2")
Master Carton Dimensions 112x58x69 (cm) - Cordoba Triangle Master Carton (6 Pack)
Neck Thickness 1st Fret 21mm
Neck Thickness 9th Fret 24mm
Nut Width 48mm (1 7/8")
Overall Length 978mm (38 1/2")
Scale Length 650mm (25.6")
Shipper Carton Dimensions 104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case)
Soundhole Diameter 84mm (3.3")
Target Instrument Weight 3.5 lbs / 1.6 kg
Upper Bout Width 279mm (11")
Compatible Case 1 Protege Classical (part#98-034-0300)
Compatible Case 2 Humi Archtop Wood Case Full Size Brwn (part#98-034-0190)
Compatible Case 3 Polyfoam Case Classical Full Size (part#98-034-0290)
Compatible Gig Bag 1 Del Gigbag Classical Full Size (part#98-034-0220)
Compatible Gig Bag 2 Standard Gig Bag Full Size (650MM Scale) (part#98-034-0230)
Country of Origin China
Does it contain shell? Yes - MOP
Frets Total 19
Headplate Flamed Okoume
Headstock Logo Cordoba Arches Logo - Mother-of-Pearl
Included Case Case Sold Separately
Number of Strings 6
Nut String Spacing 40mm
pcid 1
Pickup Type Undersaddle Piezo + Microphone, Onboard Tuner
Replacement Nut 48mm x 5mm Bone (part#98-041-0080)
Replacement Saddle 80mm x 3mm bone, Radiused (part#98-041-0210)
Replacement Truss Rod Wrench 4mm Allen Key
Rosette Maple, Black and Red Rings
Side Purfling Inlay 4-ply Maple and Black
Strings Savarez Alliance /Cantiga High Tension 510AJ
Tail Strip Mahogany
Top Binding Mahogany
Top Purfling Inlay 6-ply Maple and Black
Truss Rod Dual Action
Truss Rod Wrench 4mm Allen Key
Tuning E-A-D-G-B-E
Tuning Machines Cordoba Honeycomb
Due to ongoing product development efforts, exact specifications are subject to change from time to time.
