Specifications
Construction |
Solid Top |
Family |
Cutaway & Electric |
Style |
Fusion |
Bridge Material |
Pau Ferro |
Fingerboard Material |
Ebony |
Neck Material |
Mahogany |
Nut Material |
Bone |
Saddle Material |
Bone |
Back and Sides Wood |
Flamed Maple |
Back Binding |
Padauk |
Back Center Strip |
Padauk |
Back Purfling Inlay |
4-ply Maple and Black |
Body Top |
Solid Spruce w/ Flamed Maple Veneer |
Build |
Fusion |
Color |
White Sands |
Finish |
Gloss Polyurethane |
Frets to Body |
12 |
Neck Joint |
Dovetail |
Neck Shape |
Fusion C Shape |
Top Bracing Pattern |
Fan |
Waist Width |
235mm (9 1/4") |
Battery Pack |
Inside Preamp Compartment - 9V |
Battery Pack Installation Location |
Flip Up Preamp |
Electronics |
Fishman Presys Blend |
Replacement Tuning Machine - Bass |
Tuner Honeycomb NKL/EB BTN Bass (part#98-041-0910) |
Replacement Tuning Machine - Treble |
Tuner Honeycomb NKL/EB BTN Treb (part#98-041-0900) |
Tuning Machine Buttons |
Black |
Tuning Machine Ratio |
14:1 |
Body Depth Lower Bout |
95mm (3 3/4") |
Body Depth Upper Bout |
85mm (3 1/3") |
Body Length |
483mm (19") |
Fret Dimensions |
2.0mm (W) x 1.1mm (H) |
Lower Bout Width |
368mm (14 1/2") |
Master Carton Dimensions |
112x58x69 (cm) - Cordoba Triangle Master Carton (6 Pack) |
Neck Thickness 1st Fret |
21mm |
Neck Thickness 9th Fret |
24mm |
Nut Width |
48mm (1 7/8") |
Overall Length |
978mm (38 1/2") |
Scale Length |
650mm (25.6") |
Shipper Carton Dimensions |
104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case) |
Soundhole Diameter |
84mm (3.3") |
Target Instrument Weight |
3.5 lbs / 1.6 kg |
Upper Bout Width |
279mm (11") |
Compatible Case 1 |
Protege Classical (part#98-034-0300) |
Compatible Case 2 |
Humi Archtop Wood Case Full Size Brwn (part#98-034-0190) |
Compatible Case 3 |
Polyfoam Case Classical Full Size (part#98-034-0290) |
Compatible Gig Bag 1 |
Del Gigbag Classical Full Size (part#98-034-0220) |
Compatible Gig Bag 2 |
Standard Gig Bag Full Size (650MM Scale) (part#98-034-0230) |
Country of Origin |
China |
Does it contain shell? |
Yes - MOP |
Frets Total |
19 |
Headplate |
Flamed Maple |
Headstock Logo |
Cordoba Arches Logo - Rosewood |
Included Case |
Case Sold Separately |
Number of Strings |
6 |
Nut String Spacing |
40mm |
pcid |
1 |
Pickup Type |
Undersaddle Piezo + Microphone, Onboard Tuner |
Replacement Nut |
48mm x 5mm Bone (part#98-041-0080) |
Replacement Saddle |
80mm x 3mm bone, Radiused (part#98-041-0210) |
Replacement Truss Rod Wrench |
4mm Allen Key |
Rosette |
Maple, Black and Red Rings |
Side Purfling Inlay |
4-ply Maple and Black |
Strings |
Savarez Alliance /Cantiga High Tension 510AJ |
Tail Strip |
Padauk |
Top Binding |
Padauk |
Top Purfling Inlay |
6-ply Maple and Black |
Truss Rod |
Dual Action |
Truss Rod Wrench |
4mm Allen Key |
Tuning |
E-A-D-G-B-E |
Tuning Machines |
Cordoba Honeycomb |
Due to ongoing product development efforts, exact specifications are subject to change from time to time.
