Specifications
| Construction |
Solid Top |
| Family |
Cutaway & Electric |
| Style |
Flamenco |
| Bridge Material |
Rosewood |
| Fingerboard Material |
Rosewood |
| Neck Material |
Mahogany |
| Nut Material |
Bone |
| Saddle Material |
Bone |
| Back and Sides Wood |
Rosewood |
| Back Binding |
Maple |
| Back Center Strip |
Maple |
| Body Top |
Solid European Spruce |
| Build |
Flamenco |
| Color |
Natural (NAT) |
| Finish |
Gloss Polyurethane |
| Frets to Body |
12 |
| Neck Joint |
Dovetail |
| Neck Shape |
C Shape |
| Top Bracing Pattern |
Fan |
| Waist Width |
244mm (9 5/8") |
| Battery Pack |
Inside Preamp Compartment - 9V |
| Battery Pack Installation Location |
Flip Up Preamp |
| Electronics |
Fishman Presys Blend |
| Tuning Machine Buttons |
Black |
| Tuning Machine Ratio |
14:1 |
| Body Depth Lower Bout |
90mm (3 1/2") |
| Body Depth Upper Bout |
85mm (3 1/3") |
| Body Length |
489mm (19 1/4") |
| Fret Dimensions |
2.0mm (W) x 1.1mm (H) |
| Lower Bout Width |
368mm (14 1/2") |
| Master Carton Dimensions |
112x58x69 (cm) - Cordoba Triangle Master Carton (6 Pack) |
| Neck Thickness 1st Fret |
21mm |
| Neck Thickness 9th Fret |
24mm |
| Nut Width |
50mm (2") |
| Overall Length |
984mm (38 3/4") |
| Scale Length |
650mm (25.6") |
| Shipper Carton Dimensions |
104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case) |
| Soundhole Diameter |
84mm (3.3") |
| Target Instrument Weight |
3.5 lbs / 1.6 kg |
| Upper Bout Width |
286mm (11 1/4") |
| Controls |
Tuner, Volume, Bass, Middle, Treble, Notch, Mic Blend, and Phase Switch |
| Country of Origin |
China |
| Does it contain shell? |
Yes - MOP |
| Electronics Vendor & Model |
Fishman OEM-PSY-B03 |
| Exclusive |
No |
| Frets Total |
19 |
| Headplate |
Rosewood |
| Headstock Logo |
Cordoba Arches Logo - Maple |
| Included Case |
Case Sold Separately |
| Number of Strings |
6 |
| Nut String Spacing |
40mm |
| pcid |
1 |
| Pickup Type |
Undersaddle Piezo + Microphone, Onboard Tuner |
| psid |
1 |
| Rosette |
All Wood Traditional |
| Strings |
Savarez Cristal Corum High Tension 500CJ |
| Tail Strip |
Maple |
| Tap Plate |
Yes |
| Top Binding |
Maple |
| Top Purfling Inlay |
3-ply Maple and Black |
| Truss Rod |
Dual Action |
| Truss Rod Wrench |
4mm Allen Key |
| Tuning |
E-A-D-G-B-E |
| Tuning Machines |
Cordoba Gold and Black with Black Buttons |
| Tuning Machines Vendor & Model |
Der Jung DJCB1GK-A1B (S3) |
| Sage Item |
04709 |
Due to ongoing product development efforts, exact specifications are subject to change from time to time.
