Built with a solid European Spruce top, Cypress back and sides, soft cutaway and Fishman Presys Blend preamp, the GK Studio is the ultimate gigging instrument and a Córdoba best seller. Made for the stage, the GK Studio is constructed with a slightly thinner body depth, neck, and nut width than a traditional Spanish guitar.
Construction | Solid Top |
Family | Cutaway & Electric |
Style | Flamenco |
Bridge Material | Rosewood |
Fingerboard Material | Rosewood |
Neck Material | Mahogany |
Nut Material | Bone |
Saddle Material | Bone |
Back and Sides Wood | Cypress |
Back Binding | Rosewood |
Back Center Strip | Rosewood |
Body Top | Solid European Spruce |
Build | Flamenco |
Color | Natural (NAT) |
Finish | Gloss Polyurethane |
Frets to Body | 12 |
Neck Joint | Dovetail |
Neck Shape | C Shape |
Top Bracing Pattern | Fan |
Waist Width | 244mm (9 5/8") |
Battery Pack | Inside Preamp Compartment - 9V |
Battery Pack Installation Location | Flip Up Preamp |
Electronics | Fishman Presys Blend |
Tuning Machine Buttons | Black |
Tuning Machine Ratio | 14:1 |
Body Depth Lower Bout | 90mm (3 1/2") |
Body Depth Upper Bout | 85mm (3 1/3") |
Body Length | 489mm (19 1/4") |
Fret Dimensions | 2.0mm (W) x 1.1mm (H) |
Lower Bout Width | 368mm (14 1/2") |
Master Carton Dimensions | 112x58x69 (cm) - Cordoba Triangle Master Carton (6 Pack) |
Neck Thickness 1st Fret | 21mm |
Neck Thickness 9th Fret | 24mm |
Nut Width | 50mm (2") |
Overall Length | 984mm (38 3/4") |
Scale Length | 650mm (25.6") |
Shipper Carton Dimensions | 104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case) |
Soundhole Diameter | 84mm (3.3") |
Target Instrument Weight | 3.5 lbs / 1.6 kg |
Upper Bout Width | 286mm (11 1/4") |
Controls | Tuner, Volume, Bass, Middle, Treble, Notch, Mic Blend, and Phase Switch |
Country of Origin | China |
Does it contain shell? | Yes - MOP |
Electronics Vendor & Model | Fishman OEM-PSY-B03 |
Exclusive | No |
Frets Total | 19 |
Headplate | Rosewood |
Headstock Logo | Cordoba Arches Logo - Maple |
Included Case | Case Sold Separately |
Number of Strings | 6 |
Nut String Spacing | 40mm |
pcid | 1 |
Pickup Type | Undersaddle Piezo + Microphone, Onboard Tuner |
psid | 1 |
Rosette | All Wood Traditional |
Strings | Savarez Cristal Corum High Tension 500CJ |
Tail Strip | Rosewood |
Tap Plate | Yes |
Top Binding | Rosewood |
Top Purfling Inlay | 3-ply Maple and Black |
Truss Rod | Dual Action |
Truss Rod Wrench | 4mm Allen Key |
Tuning | E-A-D-G-B-E |
Tuning Machines | Cordoba Gold and Black with Black Buttons |
Tuning Machines Vendor & Model | Der Jung DJCB1GK-A1B (S3) |
Sage Item | 04706 |
