Specifications
Construction |
Solid Top |
Family |
Cutaway & Electric |
Style |
Flamenco |
Bridge Material |
Rosewood |
Fingerboard Material |
Rosewood |
Neck Material |
Mahogany |
Nut Material |
Bone |
Saddle Material |
Bone |
Back and Sides Wood |
Cypress |
Back Binding |
Rosewood |
Back Center Strip |
Rosewood |
Body Top |
Solid European Spruce |
Build |
Flamenco |
Color |
Natural (NAT) |
Finish |
Gloss Polyurethane |
Frets to Body |
12 |
Neck Joint |
Dovetail |
Neck Shape |
C Shape |
Top Bracing Pattern |
Fan |
Waist Width |
244mm (9 5/8") |
Battery Pack |
Inside Preamp Compartment - 9V |
Battery Pack Installation Location |
Flip Up Preamp |
Electronics |
Fishman Presys Blend |
Tuning Machine Buttons |
Black |
Tuning Machine Ratio |
14:1 |
Body Depth Lower Bout |
90mm (3 1/2") |
Body Depth Upper Bout |
85mm (3 1/3") |
Body Length |
489mm (19 1/4") |
Fret Dimensions |
2.0mm (W) x 1.1mm (H) |
Lower Bout Width |
368mm (14 1/2") |
Master Carton Dimensions |
112x58x69 (cm) - Cordoba Triangle Master Carton (6 Pack) |
Neck Thickness 1st Fret |
21mm |
Neck Thickness 9th Fret |
24mm |
Nut Width |
50mm (2") |
Overall Length |
984mm (38 3/4") |
Scale Length |
650mm (25.6") |
Shipper Carton Dimensions |
104 x 47 x 14 (cm) - Cordoba Guitar Triangle Box (No Case) |
Soundhole Diameter |
84mm (3.3") |
Target Instrument Weight |
3.5 lbs / 1.6 kg |
Upper Bout Width |
286mm (11 1/4") |
Controls |
Tuner, Volume, Bass, Middle, Treble, Notch, Mic Blend, and Phase Switch |
Country of Origin |
China |
Does it contain shell? |
Yes - MOP |
Electronics Vendor & Model |
Fishman OEM-PSY-B03 |
Exclusive |
No |
Frets Total |
19 |
Headplate |
Rosewood |
Headstock Logo |
Cordoba Arches Logo - Maple |
Included Case |
Case Sold Separately |
Number of Strings |
6 |
Nut String Spacing |
40mm |
pcid |
1 |
Pickup Type |
Undersaddle Piezo + Microphone, Onboard Tuner |
psid |
1 |
Rosette |
All Wood Traditional |
Strings |
Savarez Cristal Corum High Tension 500CJ |
Tail Strip |
Rosewood |
Tap Plate |
Yes |
Top Binding |
Rosewood |
Top Purfling Inlay |
3-ply Maple and Black |
Truss Rod |
Dual Action |
Truss Rod Wrench |
4mm Allen Key |
Tuning |
E-A-D-G-B-E |
Tuning Machines |
Cordoba Gold and Black with Black Buttons |
Tuning Machines Vendor & Model |
Der Jung DJCB1GK-A1B (S3) |
Sage Item |
04706 |
Due to ongoing product development efforts, exact specifications are subject to change from time to time.
